Sharp MultiSync® ME502
LCD 50" Message Essential Large Format Display
| Haze Level | Pro |
| Operating Hours | 18/7 |
| Brightness [cd/m²] | 450 |
| Resolution | 3840 x 2160 |
| Order Code | L50ME502 |
| Model | PN-ME502 |
Price on infomail _at_ sharp _dot_ eu
- DISPLAY
-
Panel Technology VA with Direct LED backlights Screen Size [inch/cm] 50 / 125.7 Aspect Ratio 16:9 Brightness [cd/m²] 450 Contrast Ratio (typ.) 5000:1 Viewing Angle [°] 178 horizontal / 178 vertical (typ. at contrast ratio 10:1) Colour Depth [bn] 1.073 (8bit + FRC) HDR HLG; PQ Response Time (typ.) [ms] 6 Panel Refresh Rate [Hz] 60 Haze Level [%] Pro (25) Supported Orientation Landscape; Portrait - RESOLUTION
-
Native Resolution 3840 x 2160Supported Resolutions 1024 x 768; 1280 x 1024; 1280 x 720; 1280 x 800; 1360 x 768; 1366 x 768; 1400 x 1050; 1440 x 1050; 1440 x 900; 1600 x 1200; 1680 x 1050; 1920 x 1080; 1920 x 1200; 1920 x 2160; 3840 x 2160; 4096 x 2160; 640 x 480; 720 x 480; 720 x 576; 800 x 600 - SYNCHRONISATION RATE
-
Horizontal Frequency [kHz] 15 - 135 Vertical Frequency [Hz] 23 - 76 - CONNECTIVITY
-
HDMI IN 1 Video Input; UHD (60 Hz) HDCP (2.2); Audio Input; CEC HDMI IN 2 Video Input; UHD (60 Hz) HDCP (2.2); Audio Input; CEC HDMI IN 3 ARC; Video Input; UHD (60 Hz) HDCP (2.2); Audio Input; CEC USB-A 1 USB (2.0); Peripherals USB-A 2 USB (3.0); Peripherals; USB Storage USB-A 3 USB (3.0); Peripherals; USB Storage USB-A (Service) Service USB-C 1 Video Input; UHD (60 Hz); DP alt. 1.4; HDCP (2.2); Audio Input; USB 2.0 / 3.0; 15 W Audio Output (3.5 mm) Audio Output; Line Out LAN 1 100 MBit/s RS-232C 9600 bps Remote In (3.5 mm) IR-Extender Input Detect Custom; Last; First - ELECTRICAL
-
Power Consumption [W] 85 shipping Power Savings Mode [W] < 0.5; < 2 (Networked Standby) Power Management VESA DPMS Power Supply 100-240 V AC; 50/60 Hz; internal - ENVIRONMENTAL CONDITIONS
-
Operating Temperature [°C] +0 to +40 Operating Humidity [%] 20 to 80 Storage Humidity [%] 10 to 90 Storage Temperature [°C] -20 to 60 - MECHANICAL
-
Dimensions (W x H x D) [mm] 1,118.6 x 639.2 x 62 Weight [kg] 11.7 Bezel Width [mm] 9.9 (symmetrical) VESA Mounting [mm] 4 holes; 400 x 400 (FDMI); M6 Ingress Protection IP5x (front); IP5x (back) Packaging Dimensions (W x H x D) [mm] 1,202 x 719 x 156 Packaging Weight [kg] 17.5 Colour Bezel Pantone (Process Black M) Material Metal - MEDIAPLAYER
-
Supported Video Formats MPG (Mpeg1/2 Layer 1/2/3, max res 4096x2160@60fps); MP4 (Mpeg1/2,H.264, HEVC/H.265, max res 4096x2160@60fps) - EMBEDDED COMPUTING
-
System Version Android 13 System Memory 4G RAM Internal Storage 32GB ROM Built-in Applications File Manager; Web Browser - AVAILABLE OPTIONS
-
Accessories Feet (ST-43M); Presence Sensor (KT-RC3); Soundbar (PN-ZCMS1); Speaker (SP-RM3a); Trolley (PD04-Tipster Trolley); Wall mount (PDW S 32-62 L); WiFi Dongle SI07B - REGULATORY
-
Safety and Ergonomics BSMI; CE; EMC Class B; Energy Star 8; FCC Class B; KC/KCC; PSB; RCM; RoHS; VCCI Resistance to Fire Metal backcover, plastic material certified acc. to UL94-5VB - GREEN FEATURES
-
Energy Efficiency Energy consumption: 96 kWh/1000 h; Energy efficiency class: G; LED backlight Ecological Standards EnergyStar 8.0 - 3RD PARTY CERTIFICATIONS
-
Cisco Verified for Cisco Collaboration Devices Crestron Certified for Crestron CCV2 and XiO Cloud Q-Sys Q-Sys Plug-in - ADDITIONAL FEATURES
-
Special Characteristics DICOM Simulation; HDMI ARC; Powered USB Port (15 W); Removable Logo Audio Integrated Speakers (10 W + 10 W) Shipping Content 2x AAA batteries; Display; HDMI Cable; Power Cable; Remote Control; Setup Manual Warranty 3 years warranty incl. backlight; additional services available; optional 4. + 5. year warranty extension 1 Operating Hours 18/7 External Control AMX NetLinx Support; ASCII Control Commands; Crestron Connected; HDMI CEC; Scheduled Timer Remote Management Automated Email Alerts; NaViSet Administrator 2 Security Disable HW Buttons; Disable IR Functionality; Disable IR Functionality
